JBL Cinema SB160

Details
Variations

2.1 Channel soundbar with wireless subwoofer



Extra Bass. Extraordinary sound.

The JBL Cinema SB160 features 220W system power, Dolby Digital, Optical and HDMI ARC, four powerful full range drivers and comes with a wireless subwoofer. Enjoy impressive, balanced sound with extra deep bass for movies and music entertainment. Plus, it’s Bluetooth-enabled so you can play your favorite music wirelessly from any smartphone, tablet or laptop and features a one cable HDMI ARC connection that ensures a hassle-free user experience.

Item# JBLSB160BLKAS

General Specifications

Power supply 100 - 240VAC, ~ 50/60Hz
Total speaker power output (Max. @THD 1%) 220W
Soundbar power output (Max. @THD 1%) 2 x 52W
Subwoofer power output (Max. @THD 1%) 116W
Soundbar transducer 2 x (48 x 90)mm racetrack driver + 2 x 0.5" tweeter
Subwoofer transducer 5.25", wireless sub
Operating temperature 0°C - 45°C

Audio Specifications

Max SPL 82dB
Frequency response 40Hz - 20kHz
Audio inputs 1 Optical, Bluetooth (USB is for Service only.)

Dimensions

Soundbar dimensions (W x H x D) 900 x 67 x 63(mm) / 35.4" x 2.6" x 2.5"
Subwoofer dimensions (W x H x D) 170 x 345 x 313(mm) / 6.7" x 13.6" x 12.3"
Soundbar weight 1.65kg
Subwoofer weight 5kg
Packaging dimensions (W x H x D) 975 x 195 x 445mm / 38.4" x 6.7" x 17.5"
Packaging weight (Gross weight) 8.5kg

Control and Connection Specifications

Bluetooth version 4.2
Bluetooth profile A2DP V1.3/AVRCP V1.5
Bluetooth frequency range 2402MHz - 2480MHz
Bluetooth max. transmitting power <0dbm (EIRP)
Modulation type GFSK, π/4 DQPSK
2.4G Wireless frequency range 2400 - 2483MHz
2.4G Max. transmitting power 3dBm
USB port Type A
USB rating 5VDC/ 0.5A
Supporting file format mp3, wav
MP3 Codec MPEG 1 Layer 2/3
MPEG 2 Layer 3 Yes
MPEG 2.5 Layer 3 Yes
MP3 sampling rate 16kHz - 48kHz
MP3 bitrate 80kbps - 320kbps
80kbps - 160kbps (MPEG 2.5 Layer 3) Yes
WAV sample rate 16kHz - 48kHz
WAV bitrate Up to 3000kbps

Video Specifications

HDMI Video output (With Audio return channel) 1
HDMI HDCP version 1.4
Click here for a complete list of all specs for this product

Spec Sheet (English)

English 714 KB
  • Soundbar
  • Wireless subwoofer
  • Remote control with batteries
  • Power cords (up to 8pcs depending on region SKUs)
  • HDMI cable
  • Wall-mount bracket kit with screws
  • Quick start guide
  • Warranty card
  • Safety sheet
